ESP8266 LED Matrix Bar Weather Station V1 - gClock/Weather/Message Scrolling Web Server (2)

Features: ESP8266 WeMos D1 mini module which I finally found good application for (now you can buy better cheap ESPs) 6 x LEDMatrix module with MAX7219 driver supplied directly from USB port with USB plug all data are synchronized every 7-8 minutes time and date are taken from google.com weather informations are grabbed from openweather.org JSON api no hardware RTC clock is necessary internal temperature, humidity sensor (options - DS18B20, DHT22, DHT12) ESP8266 setup and control as a Wi-Fi Web Server (WiFiManager, OTA, mDNS) receives a message input from a User Input page, then displays the message on a scrolling LED matrix display. The interface for all the controls is designed as a webapp for internet browser. 6 x MAX7219 8 x 8 LED Matrix module 1 x WeMos D1 mini 1 x Interface Shield Schematic is available here: Normal: https://easyeda.com/neoseven/led-matr... Expansion: https://easyeda.com/neoseven/led-matr... (Unfinished - Future plans) Source code is available here: V1: https://github.com/ZalophusDokdo/LED_... =================================================== Configuring the upload environment =================================================== How to configure standard Arduino IDE to use as Arduino ESP8266 IDE. First download Arduino IDE and install it on computer. IMPORTANT: Download old version Arduino IDE Version 1.8.1. (Tested Version 1.8.9 and Version 1.8.13) Open Arduino IDE and go to File - Preferences. Enter http://arduino.esp8266.com/stable/pac... under Adittional boards manager. Select Boards Manager in Tools - Board Find ESP8266 and press Install IMPORTANT: Download old version esp8266 by ESP8266 Community Version 2.3.0. IMPORTANT: Additional Libraries go to Sketch - Include Library - Manage Libraries Find and Install WiFiManager by tzapu,tablatronix Version 0.15.0 DHT Sensor library by Adafruit Version 1.3.0 ArduinoJson by Benoit Blanchon Version 5.11.1 After install select ESP9266 board. Board: NodeMCU 1.0 (ESP-12E Module) Upload Speed: "115200" CPU Frequency: "80 MHz" Flash Size: "4M (3M SPIFFS)" Port: COM?? =================================================== 3D Parts: Pinshape : https://pinshape.com/items/46659-3d-p... Thingiverse : https://www.thingiverse.com/thing:265... The open source hardware and software is free and made with love. Please show your level of support with a voluntary donation. Donate: https://www.paypal.com/cgi-bin/webscr...
