How to install a RocketCPU WPC-89-S in a Bally Williams pinball machine
The RocketCPU is a drop-in replacement board for your original WPC-89 or WPC-S CPU. Fully compatible with your Bally / Williams pinball machine. This tutorial video will guide you for the RocketCPU WPC-89-S setup, from start to finish. Exact same schematics as original, with some extra features: integrated No More Reset, CR2032 battery, remote battery holder, shrouded ribbon connectors, high accuracy clock and more. _______________________________________________________________________ ð Buy your RocketCPU here : https://www.pinsound.org/shop/en/102-... _______________________________________________________________________ ð§ Visit our site for more information: https://www.pinsound.org ðĩ Follow us on Facebook:   / pinsound  ð· Follow us on Instagram:   / pinsoundpinball  _______________________________________________________________________ 0:00 Intro 0:07 1) Open the backbox 0:21 2) Disconnect and remove the Original CPU 1:13 3) Remove the Asic U9 1:27 4) Remove Eprom U6 1:35 5) Remove Processor U4 1:54 6) Transfer Asic U9 to RocketCPU 2:13 7) Transfer Processor U4 to RocketCPU 2:29 8) Transfer Eprom U6 to RocketCPU 2:44 9) Insert CR2032 Batteries 2:52 10) Install the RocketCPU in the backbox 3:25 11) Check the Smart Status LED 3:39 Visit our website for more info
