7–53. Draw the shear and bending-moment diagrams for the beam. #statics

Problem 7–53 Draw the shear force diagram and bending moment diagram for the given beam. In this video, we solve Problem 7–53 by drawing the Shear Force Diagram (SFD) and Bending Moment Diagram (BMD) for a beam subjected to the specified loading and support conditions. The solution is explained in a clear, step-by-step approach, beginning with the free body diagram, followed by: Calculation of support reactions Division of the beam into appropriate sections Derivation of shear force equations Derivation of bending moment equations Identification of key values and critical points Construction of accurate SFD and BMD This problem is fundamental for understanding beam behavior under loading and is highly relevant for engineering exams and structural analysis fundamentals. This video is ideal for: Civil Engineering students Mechanical Engineering students Strength of Materials courses Engineering Mechanics courses Exam and homework preparation #ShearForceDiagram #BendingMomentDiagram #SFD #BMD #StrengthOfMaterials #BeamAnalysis #StructuralAnalysis #CivilEngineering #MechanicalEngineering #EngineeringMechanics
