Do You Know Your PVC Conduit - Sizes, Types, Colour, Saddles, Expansion Coupler & Boxes - Explained
In this video we look at the different colour, sizes, types, fixing and boxes available for PVC conduit. This video will help learners at level 1, level 2 and in the early stages of an electrical apprenticeship. Plastic conduit for electrical wiring PVC conduit colours - black and white PVC conduit sizes - 16mm, 20mm 25mm and 32mm PVC conduit types - heavy gauge and light gauge PVC conduit saddles - plain saddle, crampet and spacer bar saddle PVC conduit Boxes - end box, tee box, through box, angle box, tangent box, terminal box, inspection box, elbows, back entry, and 4 way boxes How and why we need to use expansion couples In long straight runs of PVC conduit == ð Time Stamps - Cut to the action ð == 00:00 - All about PVC conduit 01:18 - Sizes of PVC conduit 01:49 - Black and white WHY... 03:01 - Saddles 04:38 - Male and female adaptors 05:09 - Different types of conduit boxes 05:53 - PVC conduit glue (solvent weld) 06:05 - PPE 07:15 - Expansion coupler 08:49 - Inspection boxes ðĩ How to Bend and Cut 20 mm PVC Conduit (90 Degrees Bend Using a Bending Spring)    âĒ How to Bend and Cut 20 mm PVC Conduit (90 ...  ðĩ How to Workout the Cable Capacities of Conduit Appendix E On-Site Guide BS 7671 Calculations Part 1    âĒ How to Workout the Cable Capacities of Con...  ðĩ How to Workout the Cable Capacities of Conduit Appendix E On-Site Guide BS 7671 Calculations Part 2    âĒ How to Workout the Cable Capacities of Con...  âïļ link to my conduit notes on the eFIXX apprentice hub https://www.efixx.co.uk/Apprentice%20... Videos are training aids for City and Guilds (C and G) and EAL courses Level 1, 2, 3 plus AM2, AM2S and AM2E. You can follow me day by day on Facebook, Instagram, Twitter and TikTok lookout for "GSH Electrical. âķïļ FACEBOOK   / gshelectrical  âķïļ INSTAGRAM   / brihzmraygdtmjmdb9lunqodmevqsbddki3qpq0  âķïļ TWITTER   / gsh_electrical  âķïļ TikTok https://vm.tiktok.com/ZMRBLFdhe/ #GSHElectrical #Electricaltrainingvideos #conduit
