Amplitude Modulation Practical Simulation on Multisim #AM

#MindsRiot #Amplitude #Modulation Amplitude Modulation Practical Simulation on Multisim Modulation: Superimposing INFORMATION SIGNAL on CARRIER SIGNAL AM: Amplitude of carrier varies with amplitude of info. signal FM: Frequency of carrier varies with amplitude of info. signal Values of components R1=68K R2=22k Rc=100 ohm Cin=1uF Ce=Cc=10uF Tuned circuit components L=100uH C=47nF Information signal: 1Vp-p & 1KHz Carrier signal: 2 Vp-p & 5KHz 2 Vp-p & 10KHz 2 Vp-p & 15KHz 2 Vp-p & 20KHz 2 Vp-p & 25KHz PEC (22334) experiment No. 03
