STATIC STRUCTURE ANALYSIS ON Simply supported BEAM with Centre load ansys example 3

This is ANSYS 19.1 tutorial for beginners. Video explains and demonstrates how to perform static structural analysis in the ANSYS workbench for the 2019 release. GEOMETRY DETAIL :-200mm*200mm*4m FORCE :- 100KN RESULT:- TOTAL DEFORMATION, STR4ESS ,STRAIN This video will help you to understand the overall workflow required in ANSYS to run your first example.
