Development of Lateral Surfaces of Solids- Cylinder 02

A vertical cylinder of base diameter 50 mm and axis length 60 mm is cut by two planes which are perpendicular to VP and inclined at 45° to HP and passing through the either side of the center point of the top face. Draw the development of the lateral surface of the cylinder.
