INTELLITRONIX 6-Gauge 3D Universal Analog AP10002
People will rave about the 6-Gauge Universal Analog 3D Panel that is equipped with speedometer, tachometer for 8-, 6-, 4-cylinder engines, fuel level, voltmeter, oil pressure, and water temperature gauges, as well as a digital clock, turn signal indicators, and high beam indicator all wrapped up into a brushed stainless steel faceplate with chromed aluminum bezel. In addition, the 6-Gauge Universal Analog 3D panel comes complete with a printed circuit board, a smoked plexiglass faceplate, universal temperature sending unit, oil pressure sending unit, and speedometer sending unit with hardware kit and installation instructions. Works with any mechanical or electronic transmissions or you can purchase separately a GPS speedometer sender from Intellitronix. Dimensions are 17" length x 4 3/4" height x 2 3/4" wide. Speedometer reads up to 160 MPH includes one button calibration, regardless of tire size, gear ratio, or transmission, odometer, trip meter, high speed recall, 0-60 time, and ¼ mile elapsed time, all with the push of a button! Tachometer reads from 0 to 8000 in 100 RPM increments Voltmeter with high and low voltage alarm reads from 8.0 to 18.0 volt range Oil Pressure reads from 0-100 PSI Water Temperature displays from 100-250 degrees Fahrenheit Fuel Level is user programmable to work with Ford, GM, Chrysler, VDO, and aftermarket 240-33 ohm industry standard fuel senders, reads from 0-99% Right and Left LED turn signal indicators High Beam LED indicator Digital Clock Automatic nighttime dimming The Speedometer sending unit is included, but if you need a Ford sending unit, then please add a note at checkout and we will send one--otherwise, you will get the GM/Mopar/VW one and will have to order the Ford one separately. Water temperature sending unit is included. Please add a note at checkout if you need a 3/8" bushing, because we send the more common 1/2" bushing--otherwise, you will have to supply the bushing on your own. Oil pressure sending unit. Know Before You Buy! If you have a LS engine, then please be aware that you will need to purchase adapters P/N 8014LS for imperial to metric for the sending units. If your LS engine is 4-cylinder, then please add a note at checkout letting us know, so that we can set the tachometer accordingly. The tachometer is programmable, you can set it yourself if it comes set differently. Easy Install, Lifetime Warranty, Great Price, & Gauges that bring your truck to the next level. FEATURES: AVAILABLE COLORS: White, Red, Blue and Green ACCESSORIES: All required sending and sensor units are included. INTELLITRONIX CORP. 34099 Melinz Parkway, Unit E Eastlake, OH 44095 T: 440-359-7200 www.intellitronixgauges.com [email protected] [email protected] https://intellitronixgauges.com/ #3d #led #digital #gauges #instruments #directfit #speedometer #tachometer #watertemperature #oilpressure #voltmeter #clock #gauge #replacement #dash #automotive #aftermarket #6-gauge
