Calculating Non-Inverting Op Amp Gain Example Problem

Calculating Non-Inverting Op Amp Gain Example Problem

This is similar to problem 4.15 in "Circuit Analysis and Design" by Ulaby, Maharbiz, and Furse. This is a free/open educational textbook on basic circuit design found here: https://cad.eecs.umich.edu/ We will find the gain of a non inverting op amp. We will also determine the source voltage range under which this op amp operates with linear gain.
